    EI / AIW 220 5.00 * 0.30 mm Enamelled Copper Magnet Wire Ultra Thin For Notebook Coil

    Ask Lasest Price
    Brand Name : Rvyuan
    Model Number : 5.00mm*0.30mm
    Certification : IEC/NEMA/JIS/RoHS/ISO/UL
    Price : Negotiation
    Payment Terms : Negotiation
    Supply Ability : 200 Ton/Tons per Month
    Delivery Time : 2-15 workding days
    • Product Details
    • Company Profile

    EI / AIW 220 5.00 * 0.30 mm Enamelled Copper Magnet Wire Ultra Thin For Notebook Coil

    EI / AIW 220 5.00 * 0.30 mm Enamelled Copper Magnet Wire Ultra Thin For Notebook Coil

    Rectangular enameled copper winding wire is a core product in everyday products and modern infrastructure, and we offer a complete range of copper wire for all kinds of applications. Round and rectangular enameled copper wire Besides the wide standard range we offer customer specific solutions, tailor-made to suit every possible needs. Whether standard or special, all our winding wire is manufactured in a high-precision process using state-of-the-art technology and manned by dedicated professionals.


    CharacteristicsStandardTest Result
    AppearanceSmooth EqualitySmooth Equality

    Conductor Diameter

    Width5.00±0.0604.981
    Thickness0.30±0.0090.297
    Thickness of Insulation
    Width0.0200.030
    Thickness0.0300.050
    Overall DiameterWidth5.1005.011
    Thickness0.3500.347
    PinholeMax. 3hole/m0
    ElongationMin. 30 %41
    Flexibility and AdherenceNo crackNo crack
    Conductor Resistance (Ω/km at 20℃)Max 12.1511.75
    Breakdown VoltageMin. 0.70kv1.7
    Heat shockNo CrackNo Crack
    ConclusionPass

    EI / AIW 220 5.00 * 0.30 mm Enamelled Copper Magnet Wire Ultra Thin For Notebook Coil
