    0.033 - 0.076mm High Wear Resistance Triple Insulated Litz Wire Enameled Magnet Wire For Heating Elements

    Ask Lasest Price
    Brand Name : Rvyuan
    Certification : IEC/NEMA/JIS/RoHS/ISO
    Price : Negotiation
    Payment Terms : Negotiation, T/T, L/C
    Delivery Time : 2-15 workding days
    Supply Ability : Satisfy your demand
    Model Number : 0.033 - 0.076mm
    • Product Details
    • Company Profile

    0.033 - 0.076mm High Wear Resistance Triple Insulated Litz Wire Enameled Magnet Wire For Heating Elements

    0.033 - 0.076MM HIGH WEAR RESISTANCE TIRPLE INSULATED LITZ WIRE ENAMELED MAGNET WIRE FOR HEATING ELEMENTS

    This is litz wires with one or more layers of extruded jacket. The wire has all the properties of Litz wire, also has extremly insulation performance and mechanical properties.

    FEATURES

    • High wear resistance

    • Very good mechanical strength

    • Easy to strip and sold or weld

    • Exellent insulation.

    • Flame retardant

    APPLICATION

    Heating elements;
    signal transfer wire.

    0.033 - 0.076mm High Wear Resistance Triple Insulated Litz Wire Enameled Magnet Wire For Heating Elements

    SPECIFICATION

    Conductor Diameter

    Conductor Diameter

    Conductor Diameter

    Insulation Thickness

    Typical Overall diameter

    Max Overall diameter

    mm

    Number

    mm

    mm

    mm

    mm

    0.05

    110

    0.69

    0.10-0.13

    0.89

    0.95

    0.05

    150

    1.06

    0.10-0.13

    1.26

    1.32

    0.05

    225

    0.90

    0.10-0.13

    1.10

    1.16

    0.05

    360

    1.10

    0.10-0.13

    1.30

    1.36

    0.05

    550

    1.40

    0.10-0.13

    1.60

    1.66

    0.07

    55

    0.80

    0.10-0.13

    1.00

    1.60

    0.08

    19

    0.45

    0.10-0.13

    0.65

    0.71

    0.1

    35

    0.78

    0.10-0.13

    0.98

    1.24

    0.1

    45

    0.97

    0.10-0.13

    1.17

    1.23

    0.1

    120

    1.30

    0.10-0.20

    1.56

    1.75

    0.1

    180

    1.80

    0.10-0.20

    2.00

    2.20

    0.127

    19

    0.72

    0.10-0.13

    0.92

    0.98

    0.2

    7

    0.68

    0.10-0.13

    0.88

    0.94

    0.2

    10

    0.75

    0.10-0.13

    0.95

    1.01

    0.2

    20

    1.18

    0.10-0.13

    1.38

    1.44

    0.254

    7

    0.84

    0.10-0.13

    1.04

    1.30

    0.254

    15

    1.46

    0.10-0.13

    1.66

    1.72

    0.287

    19

    1.50

    0.10-0.13

    1.70

    1.76
