    0.1*60 Class 180 Taped Polyimide Film Covered Copper High Frequency Litz Wire

    Ask Lasest Price
    Brand Name : Rvyuan
    Certification : IEC/NEMA/JIS/RoHS/ISO
    Price : Negotiation
    Payment Terms : Negotiation
    Supply Ability : Satisfy your demand
    Delivery Time : 2-15 workding days
    • Product Details
    • Company Profile

    0.1*60 Class 180 Taped Polyimide Film Covered Copper High Frequency Litz Wire

    0.1*60 class 180 taped Polyimide film covered high frequency litz copper wire


    Taped high frequency litz wire constructions are mainly suitable for applications requiring a high break down voltage. Taping gives litz wire improved capability to withstand flexing and mechanical stress. Self-adhesive tape material increases protection against re-opening during and after manufacturing processes and thus secures the compliance with defined creepage distance.


    Features and benefits


    VariantsDielectric strengthFlexibilitySplicingContacting
    Standardhighvery goodgoodvery good
    Thermally Sealedelevatedmediumvery goodvery good
    Self-Adhesivevery highgoodvery goodgood

    Specification:

     CharacteristicsTechnical requestsTest ResultsConclusion
    Sample 1Sample 2Sample 3
    1SurfaceGoodOKOKOKOK
    2Breakdown Voltage≥ 3.0 KV55.36.2OK
    3Pinhole Test≤ 20 hole/6m322OK
    4Outer diameter≤ 0.116 mm0.1110.1120.113OK
    5Inner diameter0.10±0.003 mm0.0970.0980.098OK
    6Thickness of film(+0.002mm)0.025 mm0.0250.0250.025OK
    7Width of film(,,)8-15 mm101010OK
    8DirectionBunchLeftOKOKOKOK
    Film coverLeftOKOKOKOK
    9Conductor Resistance≤ 40.87 Ω/km31.6932.0132.08OK
    10Overall Diameter≤ 1.25 mm0.8740.8960.902OK
    Remark:Conclusion:
    Approved
    Audit byTested by
     Pan Lihong

    Certificates:


    ISO 9001-2000, ISO TS 16949, ISO 14001-2004,
    UL Approved, RoHS Directive Met

    Application:

    1. Transformer Insulation Wire of Power Supplier & AC/DC Adapters,

    2. Mobile Phone Battery Chargers and Ring Coil & Choke & PC Computer,

    3. Netebook Computer,

    4. Digital Camera Insulation wire.


    Company information


    Exquisite,High quality, all for customers is not a slogan but the value of our people that exist in our blood.
    Every day, the first idea in our mind is how to improve ourselves and our rules to provide a better service and experience not only procurement but also good feel during inquiry, talking.

    We also enrich our professional knowledge in different industries and applications, so our role is not just one of best provider of enmaled copper wire but a trustable consult in different applications.

    Welcome to contact us! And our team are waiting for helping you!
