    1300v 0.1mm * 250 Nylon Covered Insulated Copper Litz Wire

    Ask Lasest Price
    Brand Name : Ruiyuan
    Model Number : 0.1*250
    Certification : UL/ISO9001/ISO14001/RoHS/Reach
    Price : Negotiation
    Payment Terms : Negotiation
    Supply Ability : Negotiation
    Delivery Time : 2-15 days
    • Product Details
    • Company Profile

    1300v 0.1mm * 250 Nylon Covered Insulated Copper Litz Wire

    USTC 155 1300V 0.1mm * 250 Nylon Covered Insulated Wire Enamel Stranded Copper Litz Wire

    Litz wire employs a stranded wire with individually insulated conductors (forming a bundle). The covering with silk can improve the winding efficiency, especially at high speed.


    USTC WIRE 0.1*250
    Technical requests
    Conductor diameter(mm)
    0.10±0.003
    No. Of strands
    250
    Maximum outer diameter(mm)
    2.39
    Pitch(mm)
    32±3
    Maximum Resistance(Ω/km 20℃)
    9.34
    Minimum Breakdown Voltage(V)
    1300
    Solderability
    390±5℃, 9s

    1300v 0.1mm * 250 Nylon Covered Insulated Copper Litz Wire
