    44 Awg Polyurthane Enamel Coil Wire To Guitar Pickup

    Ask Lasest Price
    Brand Name : Ruiyuan
    Model Number : 0.05mm
    Certification : UL/ISO9001/ISO14001/RoHS/Reach
    Price : Negotiation
    Payment Terms : Negotiation
    Supply Ability : 100Ton/week
    Delivery Time : 2-15 days
    • Product Details
    • Company Profile

    44 Awg Polyurthane Enamel Coil Wire To Guitar Pickup

    44 Awg Polyurthane Enamel Coil Wire To Guitar Pickup44 Awg Polyurthane Enamel Coil Wire To Guitar Pickup

    44 AWG Polyurethane guitar pickup wire

    Rvyuan has been “Class A” provider for guitar pickup craftsmen and pickups makers around the world over two decades. Apart from universally used AWG41, AWG42, AWG43 and AWG44, we also help our customers explore new tones with different sizes on their requests, such as 0.065mm, 0.071mm etc. Most popular material at Rvyuan is copper, there are also pure silver, gold wire, silver plated wire available if you need.


    Test Item

    Standard Value

    Test Result

    Conductor Diameter

    0.050±0.002mm

    0.050mm

    Thickness of insulation

    Min. 0.007

    0.0094mm

    Overall diameter

    Max. 0.060mm

    0.0594mm

    Continuity of covering
    (50V/30m)

    Max. 60 pcs

    Max. 0 pcs

    Breakdown voltage

    Min. 400V

    Min. 1,628V

    Resistance to softening

    Continue 2 times pass

    230℃/Good

    Solder test(390℃±5℃)

    Max. 2s

    Max. 1.5s

    D.C Electrical resistance(20℃)

    8.6-9.0 Ω/m

    8.80 Ω/m

    Elongation

    Min. 12%

    23%

    Product

    44 AWG Polyurthane guitar pickup wire

    Conductor diameter

    0.05mm

    Key word

    44 AWG Polyurthane guitar pickup wire

    Coating

    Polyurthane
