    AWG 46 0.04mm Ultra Fine Enamelled Copper Wire For Magnetic Head

    Ask Lasest Price
    Brand Name : Ruiyuan
    Model Number : AWG 46
    Certification : UL/ROHS/ICE/ISO9001/ISO14001
    Price : Negotiation
    Payment Terms : Negotiation
    Supply Ability : 200 Ton/Tons per Month
    Delivery Time : 2-15 days
    • Product Details
    • Company Profile

    AWG 46 0.04mm Ultra Fine Enamelled Copper Wire For Magnetic Head

    AWG 46 0.04mm Ultra Fine Enamelled Copper Wire For Magnetic Head


    We are one of the pioneers in producing micro thin enameled wires below 0.03mm in China. Our R & D team has 20 years of market experience.We have achieved the goal of "zero pinholes after stretching" for ten years. In 2019, our finest diameter is 0.011mm, and mass production has been achieved.When the displays return the transformer industry, we are the No.1 Chinese brand with a share of cake.We rival the internationally renowned enameled wire brands for production, technology, raw materials.We surpass them in terms of "service, quick response"; 30% lower "price" is our advantage. More and more well-known customers choose us as suppliers-Philips, Bosch, Panasonic, Samsung ...


    We have a long history of producing self-adhesive lines. Since the beginning of our factory, we have started to develop and produce self-adhesive lines. Because of our strong R & D strength, our products have a wide range of applications.We have a full range of self-adhesive lines and a wide range of applications.Thermal class is155C, 180 C, 200 C, 220 C. Conductor material includes enameled round wire, enameled copper-clad aluminum wire


    AWG 46 0.04mm Ultra Fine Enamelled Copper Wire For Magnetic Head


    SPECIFICATION

    CharacteristicsTechnical requestsTest ResultsConclusion
    Sample 1Sample 2Sample 3
    SurfaceGoodOKOKOKOK
    Bare Wire Diameter0.040±0.0010.040.040.04OK
    0.001
    Coating Thickness≥ 0.006 mm0.0110.010.01OK
    Overall Diameter≤ 0.052 mm0.0510.050.051OK
    Conductor Resistance≤ 14.433 Ω/m13.73613.76813.771OK
    Elongation≥ 11 %141516OK
    Breakdown Voltage≥ 325 V11781076948OK
    Pinhole Test≤ 5 hole /5m000OK
    Continuity--------------------
    Test ItemsTechnical Requests
    AdhesiveCoating layer is goodOK
    Cut-through200℃ 2min no breakdownOK
    Heat Shock175±5℃/30min no crackOK
    Solder Ability390± 5℃ 2Sec SmoothOK
