    55 Awg 0.014mm Watch Super Enamelled Copper Wire

    Ask Lasest Price
    Brand Name : Ruiyuan
    Model Number : 0.014mm
    Certification : UL/ISO9001/ISO14001/RoHS/Reach
    Price : Negotiation
    Payment Terms : Negotiation
    Supply Ability : Negotiation
    Delivery Time : 2-15 days
    • Product Details
    • Company Profile

    55 Awg 0.014mm Watch Super Enamelled Copper Wire

    55 awg 0.014mm UEW155 Super Thin Magnetic Wire Enameled Copper Wire For Watch


    We are one of the pioneers in producing ultra-fine enameled wires below 0.03mm in China. Our R & D team has 20 years of marketexperience.We have achieved the goal of "zero pinholes after stretching" for ten years. In 2019, our finest diameter is 0.011mm,and mass production has been achieved.When the displays return the transformer industry, we are the No.1 Chinese brand with ashare of cake.We rival the internationally renowned enameled wire brands for production, technology, raw materialsWe surpass them in terms of "service, quick response"; 30% lower "price" is our advantage.


    3UEW155 0.014mm
    Test item
    Standard value
    Reality value
    Conductor dimensions(mm)
    0.014mm±0.001
    0.014
    0.014
    0.014
    Overall dimensions(mm)
    Max.0.017mm
    0.0168
    0.0168
    0.0168
    Insulation film thickness(mm)
    Min.0.002
    0.0028
    0.0028
    0.0028
    Continuity of covering(50V/30M)PCS
    Max.60
    Max.0
    Breakdown voltage(v)
    Min.100
    Min.243
    Resistance to softening(cut through)℃
    Continue 2 times pass
    200℃/Good
    Solder test(390℃±5s
    Max.2
    Max.1.5
    Electrical resistanceΩ/m
    98-115
    108.6
    108.6
    108.6
    Elongation%
    Min.3
    10
    10
    10

    55 Awg 0.014mm Watch Super Enamelled Copper Wire
